Outdoor portable power bank
High-powered at 1000W output, perfect for outdoor photography, filming, construction work, residential power outages, night market booth equipment, and temporary power supply needs while on-the-go. Made with high-quality lithium iron phosphate batteries, which have a high safety factor, less prone to thermal runaway, and can have a lifespan of up to 10 years with over 3000 cycles.
Description
Features of Outdoor portable power bank
Applicable scenario
High-powered at 1000W output, perfect for outdoor photography, filming, construction work, residential power outages, night market booth equipment, and temporary power supply needs while on-the-go.
Smart BMS
Real-time protection with overcharging, over discharging, overloading, short-circuit, and over temperature protection functions to safeguard the battery.
Multiple output interface
220VAC outlet ×3, USB fast charging outlet ×3, Type-C/65W fast charging outlet ×1, smoke holder ×1, 5521 outlet ×1.
LCD smart display
LCD smart display, real-time reading work data.
LFP Battery
Made with high-quality lithium iron phosphate batteries, which have a high safety factor, less prone to thermal runaway, and can have a lifespan of up to 10 years with over 3000 cycles.
Multiple charging modes
Supports charging through various methods, including solar power, wind power, diesel, and the electricity grid.
Specifications of Outdoor portable power bank
| Model | NP-XT1200A | NP-XT1200B |
| Size | 300×210×220mm | 300×210×220mm |
| Weight | 8.2KG | 11.9KG |
| Nominal voltage | 12.8V | 12.8V |
| Nominal capacity | 50Ah | 100Ah |
| Nominal capacity | 640Wh | 1280Wh |
| Maximum output current | 100A | 100A |
| Power output | 1000W (After reaching the peak output of 1800W, the output will be adjusted to 1200W ≤30ms) | |
| Output voltage | 220VAC-240VAC | |
| Output wave form | Pure sine wave | |
| Frequency of output | 50HZ/60HZ | |
| Efficiency of conversion | ≥90%（Resistive load） | |
| AC outlet x 3 | 220-240VAC 1200W (Total power) | |
| USB output x2 | 5VDC 4.8A(Total current current) | |
| USB output x1 | 5V/9V DC 2.4A(current) | |
| Type-C outputs x1 | 65W 5/9/12/15/20VDC,3A20VDC,5A(Embedded identification chip) | |
| Cigarette outlet output×1 | 12VDC.10A/120W | |
| 5521 output times 3 | ||
| MPPT Input current | 15A（MAX） | |
| Protection Function | Over voltage, low voltage, overload, short circuit, over temperature | |
| Operating ambient temperature | 0-40℃ | |
| Temperature of charge | 0-40℃ | |
| Temperature of discharge | -20℃-40℃ | |
| Relative humidity | 10-90% | |
| Noise at work | ≤54dB | |
