Smart Solar Power Station
Independent household,communication base station,island fishing boat,remote mountain area,computer room,municipal engineering, RV, stable as municipal electricity,anti-interference, no harm to electrical appliances. Designed with wall-mounting feature, which saves a lot precious space during installation.
Description
Features of Smart Solar Power Station
Applicable scenario
Independent household,communication base station,island fishing boat,remote mountain area,computer room,municipal engineering, RV, stable as municipal electricity,anti-interference, no harm to electrical appliances.
Smart BMS
Real-time protection with overcharging, over discharging, overloading, short-circuit, and over temperature protection functions to safeguard the battery.
Multiple output interface
Three-hole socket ×2, USB 5V DC ×2, 12V DC startup (ESC) x 1, 12V DC round hole ×4, Solar Charger Connector (+ and -) Battery Switch.
Smart Portable design
Designed with wall-mounting feature, which saves a lot precious space during installation.
LFP Battery
Made with high-quality lithium iron phosphate batteries, which have a high safety factor, less prone to thermal runaway, and can have a lifespan of up to 10 years with over 3000 cycles.
Multiple charging modes
Supports charging through various methods, including solar power, wind power, diesel, and the electricity grid.
Specifications of Smart Solar Power Station
| Model | LI-300 | LI-600 | LI-1000 |
| Inverter output voltage | AC 220V ± 5 % | ||
| Mains power input range | 156v-265v | ||
| Output frequency | 50 ±3HZ | ||
| Output waveform | Correction wave | Pure sine wave | |
| Conversion efficiency | ≥90% | ||
| Maximum continuous power | 350W | 600W | 1000W |
| Peak power | 500W | 1000W | 1200W |
| No load current | ≦0.3A | ≦0.8A | ≦1A |
| Charging voltage | 14.6v | 14.6v | 14.6V |
| Built in controller | 12v/30A | ||
| Recommended solar panels | 200W-300W/18V | 300W-400W/18V | |
| Battery Energy | 30AH | 50AH | 100AH |
| Cycle life | ≥2000 Cycles | ||
| Operating environment | 10℃-60℃ Reduced capacity use | ||
| Nominal voltage | 14.2v | ||
| Battery voltage | 12.8v | ||
| Discharge termination voltage | 10v | ||
| USB Output voltage | 5 ± 0.3V | ||
| USB Output current | 2A/4A | ||
| DC output port(L1-L4) | 12V/10A | ||
| Automobile starting power | EC5 With. EC5 interface | ||
| Cigarette lighter | Optional. EC5 turn point cigarette end | ||
| Overload/short circuit protection | Yes | ||
| High-temperature protection | With. 90 ℃ protection | ||
| Low voltage alarm | 10.5v ± 0.3V | ||
| Cooling mode | Fan cooling | ||
